603‐E/F
Applicationno.5

Opensystemwithtappingfromreturnpipe

Heatenergy:E1=V1(t1‐t2)k
t1:Inlet


Tapwaterenergy:E5=V2(t2‐t3)k
t2:Inlet


t3ismeasuredorprogrammed

Mass:M1=V1(Kmasst1)
Mass:M2=V2(Kmasst2)




Config.A=3(Inlet)


603‐E/F
Applicationno.6

Opensystemwithsep arateflowsensorfortapping

Heatenergy:E1=V1(t1‐t2)k
t2:Outlet


Tapwaterenergy:E6=V2(t3‐t4)k
t3:Inlet


t3ismeasuredorprogrammed
t4isprogrammed.

Mass:M1=V1(Kmasst1)
Mass:M2=V2(Kmasst3)*




Config.A=4(outlet)

*M2=V2(Kmasst3).V2ismass‐adjustedwitht3whenselectingspecialDDD‐code.

