Series 2280 Precision DC Power Supply Reference Manual Section 3: Functions and features
077085503 / March 2019 3-37
Importing a list from an external USB flash drive
If you have created or saved a list file (.csv file), you can import the list from external USB flash
drive. See the following figure for an example of a list .csv file.
Figure 72: Example of a list sheet
Before importing a list, make sure the external USB flash drive is connected to the instrument.
To import a list from USB flash drive on the front panel:
1. Press the Menu key.
2. Under Source, highlight the List icon using either the navigation control or the soft keys. Press
the ENTER key. The Source List screen is displayed.
3. Select Import and press the ENTER key. The list file selection screen is displayed.
4. Select a list that you want to import to the instrument and press ENTER. The list location
selection screen is displayed.
5. Enter a list location where you want to save the list and press ENTER.
When you import a .csv file, make sure the filename is less than 8 characters. If the filename is
more than 8 characters, the file is not imported to the instrument and a warning screen is displayed.
