Series 2280 Precision DC Power Supply Reference Manual Section 7: SCPI command reference
077085503 / March 2019 7-21
CALCulate subsystem
The commands in this subsystem configure and control the math and statistic operations.
:CALCulate[1]:<function>:FORMat
This command specifies which math operation is performed on measurements.
Type
Affected by
Where saved
Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
MXB
Usage
:CALCulate[1]:<function>:FORMat <name>
:CALCulate[1]:<function>:FORMat <name>,<channel>
:CALCulate[1]:<function>:FORMat?
:CALCulate[1]:<function>:FORMat? <channel>
<function>
The measurement function to which this setting applies:
 Concurrent: CONCurrent[:DC]
 Current: CURRent[:DC]
 Voltage: VOLTage[:DC]
<name>
The name of the math operation:
 y = mx + b: MXB
<channel>
The channel number (default value is CH1):
 Channel 1: CH1
Channel 2: CH2
Details
This command specifies which math operation is performed on measurements for the selected
measurement function.
You can choose the math operation y = mx + b, and math calculations are applied to the input signal
after filter and relative offset operations.
y = mx+b: Manipulates normal display readings by adjusting the m and b factors.
Example
:CALC:VOLT:FORM MXB
Set the math function for voltage measurements to mx + b.
Also see
:CALCulate[1]:<function>:KMATh:MBFactor (on page 7-22)
:CALCulate[1]:<function>:KMATh:MMFactor (on page 7-23)
:CALCulate[1]:<function>:KMATh:MUNits (on page 7-25)
:CALCulate[1]:<function>:STATe (on page 7-26)
