Appendix D: Status model Series 2280 Precision DC Power Supply Reference Manual
D-2 077085503 / March 2019
The structure of status model is shown in the diagram in Status model structure (on page D-2). The
relationship between Questionable Event Register, Questionable Instrument Event Register, and
Questionable Instrument Summary Event Register is shown in the diagram in Questionable registers
(on page D-3).
The relationship between Operation Event Register, Operation Instrument Event Register, and
Operation Instrument Summary Event Register is shown in the diagram in Operation registers (on
page D-4).
The relationship between Measurement Event Register, Measurement Instrument Event Register,
and Measurement Instrument Summary Event Register is shown in the diagram in Measurement
registers (on page D-4).
