Keithley 2280S-32-6 - Sense[N]:<Function>:Range

Series 2280 Precision DC Power Supply Reference Manual Section 7: SCPI command reference
077085503 / March 2019 7-67
:SENSe[n]:<function>:RANGe
This command sets the measurement range for measurements of the selected function.
Type
Affected by
Where saved
Default value
Command and query
Power cycle
Save settings
Concurrent: 10 mA
Current: 10 mA
Voltage: 33 V for Model 2280S-
32-6; 61 V for Model 2280S-60-3
Usage
:SENSe[n]:CONCurrent[:DC]:RANGe <range>
:SENSe[n]:CONCurrent[:DC]:RANGe?
:SENSe[n]:CONCurrent[:DC]:RANGe? DEFault
:SENSe[n]:CONCurrent[:DC]:RANGe? MINimum
:SENSe[n]:CONCurrent[:DC]:RANGe? MAXimum
:SENSe[n]:CURRent[:DC]:RANGe <range>
:SENSe[n]:CURRent[:DC]:RANGe?
:SENSe[n]:CURRent[:DC]:RANGe? DEFault
:SENSe[n]:CURRent[:DC]:RANGe? MINimum
:SENSe[n]:CURRent[:DC]:RANGe? MAXimum
:SENSe[n]:VOLTage[:DC]:RANGe <range>
:SENSe[n]:VOLTage[:DC]:RANGe?
[n]
Channel number: For single-channel instruments, the value is 1
<range>
Set this command to a specific value or a preset value. See Details.
Details
This command is primarily intended to eliminate the time that is required by the instrument to select
an automatic range.
The options for <range> are described in the following table.
Measurement function
Measure ranges
Concurrent
0.01 A, 0.1 A, 1 A, and 10 A
Current
0.01 A, 0.1 A, 1 A, and 10 A
Voltage
32 V for Model 2280S-32-6; 60 V for Model 2280S-
60-3
When you select a fixed range, an overrange condition can occur.
When you set a value for the measurement range, the measurement autorange setting is
automatically disabled for the measurement function.
