Series 2280 Precision DC Power Supply Reference Manual Section 7: SCPI command reference
077085503 / March 2019 7-87
Example
After each list step, the instrument generates a
measure complete pulse.
Also see
Digital I/O (on page 3-19)
[:SOURce[n]]:LIST:RCL
This command recalls a specific list.
Recall settings
Instrument reset
Power cycle
Usage
[:SOURce[n]]:LIST:RCL <listNumber>
[:SOURce[n]]:LIST:RCL?
Channel number: For single-channel instruments, the value is 1
Details
Before you run a list, you need to recall this list. If you forget to recall a list, the last recalled list is
used. Sending the command :LIST:RCL? returns the active list number.
Example 1: Sweep list with BUS trigger (hold time type: TIME)
*RST
Define list
:LIST1:VOLT "1, 2, 3, 4, 5"
:LIST1:CURR "0.5, 1, 1.5, 2, 2.5"
:LIST1:DWEL "0.5, 0.5, 0.5, 0.5, 0.5"
:LIST:SAVE:INTe 1
:LIST:RCL 1
:LIST:MCOMP SWEEP
:LIST:HTIMe TIME
Define trigger model (sweep)
:ARM:SOUR BUS
:TRIG:COUN 5
Enable list mode
:LIST:STAT ON
:INIT
*TRG
Reset the instrument and stop the trigger model
Program voltage list 1 with 5 points
Program current list 1 with 5 points
Program dwell list 1 with 5 points
Save list 1 to nonvolatile memory
Recall list 1
Select sweep mode
Set hold time type to TIME
Select the BUS arm source
Set the trigger count to list points, no need to set the
sample count for TIME mode
Enable list mode
Start the trigger model
Run the lists
Hold time is the sum of the dwell time of 5 points
All the readings will be stored in data buffer
