Keithley 2280S-32-6 Reference Manual

Appendix D: Status model Series 2280 Precision DC Power Supply Reference Manual
D-18 077085503 / March 2019
Measurement Instrument Event Register
Measurement Instrument Event Register summarizes the Measurement Instrument Summary Event
Register. If bit 1 of the Measurement Instrument Event Register is set and bit 1 of Measurement
Instrument Event Enable Register is enabled, bit 13 (ISUM) of the Measurement Event Register is
set. See the following figure and table below it for details.
Figure 132: Series 2280 Measurement Instrument Event Register
Bit
Decimal
value
Bit name
When set, indicates the following
has occurred:
0
Not used
Not used
NA
1
2
SUM1
Summary of Measurement Instrument
Summary Event Register.
2 through 15
Not used
Not used
NA
