7: TSP command reference Series 2600B System SourceMeter® Instrument Referenc

e Manual

7-168 2600BS-901-01 Rev. C / August 2016

Example 1

reset()

testData = buffer.make(200)

format.data = format.ASCII

format.asciiprecision = 6

trigger.model.load("SimpleLoop", 6, 0, testData)

trigger.model.initiate()

waitcomplete()

printbuffer(1, testData.n, testData.readings, testData.units,

testData.relativetimestamps)

This assumes that testData is a valid reading buffer in the run-time environment. The use of testData.n

(bufferVar.n) indicates that the instrument should output all readings in the reading buffer. In this example,

testBuffer.n equals 6.

Example of output data:

1.10458e-11, Amp DC, 0.00000e+00, 1.19908e-11, Amp DC, 1.01858e-01, 1.19908e-11, Amp DC,

2.03718e-01, 1.20325e-11, Amp DC, 3.05581e-01, 1.20603e-11, Amp DC, 4.07440e-01, 1.20325e-

11, Amp DC, 5.09299e-01

Example 2

for x = 1, testData.n do

printbuffer(x,x,testData, testData.units, testData.relativetimestamps)

end

Using the same buffer created in Example 1, output readings, units and relative timestamps on a separate line

for each reading.

1.10458e-11, Amp DC, 0.00000e+00

1.19908e-11, Amp DC, 1.01858e-01

1.19908e-11, Amp DC, 2.03718e-01

1.20325e-11, Amp DC, 3.05581e-01

1.20603e-11, Amp DC, 4.07440e-01

1.20325e-11, Amp DC, 5.09299e-01

Also see

bufferVar.n

bufferVar.readings

format.asciiprecision

format.byteorder

format.data

printnumber() (on page 7-169

)
