Model 6517B Electrometer Reference Manual Section 6: Test sequences
6517B-901-01 Rev. C / August 2015 6-13
ALT-POLARITY
V-OFS
V-ALT
MEAS-TIME
DISCARD RDGS
STORE RDGS
SIR
SUR-INSUL-RES-TEST
BIAS V
BIAS-TIME
MEAS-V
MEAS-TIME
Alternate polarity test:
Specify offset voltage
Specify alternating voltage
Specify measurement time
Specify discarded readings
Specify readings to store
Surface insulation resistance test:
Specify bias voltage
Specify bias time
Specify measurement voltage
Specify measurement time
0 V
10 V
15 s
3
1
+50 V
1 s
+100 V
1 s
SWEEP
SQUARE-WAVE
HI-LEVEL
HI-TIME
LO-LEVEL
LO-TIME
CYCLE COUNT
STAIRCASE
START
STOP
STEP
STEP TIME
Sweep tests:
Square wave sweep test:
Specify high level voltage
Specify time at high level
Specify low level voltage
Specify time at low level
Specify number of cycles
Staircase sweep test:
Specify start voltage
Specify stop voltage
Specify step voltage
Specify step time
+1 V
1 s
-1 V
1 s
10
+1 V
+10 V
+1 V
1 s
CONTROL
MANUAL
IMMEDIATE
LID-CLOSURE
GPIB
EXTERNAL
TRIGLINK
Select trigger source to start test:
Start when TRIG key pressed
Start immediately
Start when test fixture lid closed
Start on GPIB trigger (GET or *TRG)
Start when external trigger received
Start when trigger is received
through the specified trigger link line
Manual
Line #1
