Section 2: Getting started Model 6517B Electrometer Reference Manual
2-14 6517B-901-01 Rev. C / August 2015
Number Description Event
+860 "Interlock Violation Error" EE
+861 "Vsource Limit too low for auto" EE
+900 "Internal System Error" EE
+950 "DDC Reading overflow" SE
+951 "DDC Reading Available" SE
+952 "DDC Buffer full" SE
+953 "DDC Mode IDDC Error" EE
+954 "DDC Mode IDDCO Error" EE
+955 "DDC Trigger Overrun Error" EE
+956 "DDC No Remote Error" EE
+957 "DDC Number Error" EE
+958 "DDC Ready" SE
SE = Status event
EE = Error event
Multiple displays
Each measurement function has its own set of "multiple displays" shown in the bottom line of the front
panel display. The PREV and NEXT display keys scroll through the selections for the present
function.
The multiple displays can show a reading in a different form, or give additional information about the
reading, for example:
ï‚· Top line shows a reading.
ï‚· Bottom line shows a zero-center bar graph with adjustable limits.
To scroll through the multiple displays available for each measurement functions, repeatedly press
and release the NEXT display key. The same action with the PREV display key does a reverse scroll
through the displays.
Multiple displays that are specific to a particular function or operation are discussed later in this
section, such as the calculations display in math. Some of the displays that are common to all
measurement functions are discussed here.
