Model 6517B Electrometer Reference Manual Section 14: SCPI command reference
6517B-901-01 Rev. C / August 2015 14-69
:VSOurce:RANGe <n>
This command is used to set the V-source range for Manual V-source Ohms.
Usage
[:SENSe[1]:RESistance:MANual:VSOurce:RANGe <n>
:RANGe?
:RANGe? DEFault
:RANGe? MINimum
:RANGe? MAXimum
<n>
 0 to 1000: Specify output in volts
 DEFault: 100V range
 MINimum: 100V range
 MAXimum: 1000V range
Details
This command is used to select the optimum V-source range for Auto V-source Ohms. Specifying the
output voltage value automatically selects the most sensitive range. For example, specifying a value
less than or equal to 100 selects the 100 V range. Specifying a value greater than 100 selects the
1000 V range.
You cannot select the 100 V range if the programmed amplitude is greater than 100 V; a Settings
Conflict error results.
Also see
:VSOurce[:AMPLitude] <n> (on page 14-70)

Keithley 6517B Specifications

General

Input Impedance	>200 TΩ
Electrometer Type	Electrometer/High Resistance Meter
Current Measurement Range	20 fA to 20 mA
Display	Vacuum Fluorescent Display
Communication Interfaces	IEEE-488 (GPIB), RS-232
Power Supply	100 V / 120 V / 220 V / 240 V; 50 Hz / 60 Hz
Resistance Measurement Range	Up to 200 TΩ
