Model 6517B Electrometer Reference Manual Section 14: SCPI command reference
6517B-901-01 Rev. C / August 2015 14-11
OUTPut command summary
Command Description
Default
Parameter
SCPI
:OUTPut1

[:STATe] <b>
Enable (operate) or disable (standby)
OFF

V-source output

[:STATe]?
Query state of V-source output
:TTL[1]
Path to set polarity of digital output line 1:
:LSENse <name>
Select polarity; active high (AHIGh)
AHIGh
or active low (ALOW)
:LSENse?
Query polarity of line 1
:TTL2
Path to set polarity of digital output line 2:
:LSENse <name>
Select polarity; active high (AHIGh)
AHIGh
or active low (ALOW)
:LSENse?
Query polarity of line 2
:TTL3
Path to set polarity of digital output line 3:
:LSENse <name>
Select polarity; active high (AHIGh)
AHIGh
or active low (ALOW)
:LSENse?
Query polarity of line 3
:TTL4
Path to set polarity of digital output line 4:
:LSENse <name>
Select polarity; active high (AHIGh)
AHIGh
or active low (ALOW)
:LSENse?
Query polarity of line 4
:ROUTe command summary
Command Description
Default
parameter
SCPI
:ROUTe
:CLOSe <list>
Path and command to close specified channel:

:STATe?
Query closed channel

:CLOSe? <list>
Query specified channels (1 = closed, 0 = open)

:OPEN <list>
Open specified channel or all channels

:OPEN:ALL
Open all channels

:OPEN? <list>
Query specified channels (1 = open, 0 = closed)

:SCAN
Command path to configure and control

scan operations:

