Section 14: SCPI command reference Model 6517B Electrometer Reference Manual

14-56 6517B-901-01 Rev. C / August 2015

:OUTPut1 subsystem

[:STATe] <b>

This command is used to enable or disable the V-source.

Usage

:OUTPut1:[:STATe] <b>

[:STATe]?

<b>

 O or OFF: Disable V-source (standby)

 1 or ON: Enable V-source (operate)

Details

This command is used to control the state of the V-source.

When enabled, the V-source is placed in operate. When disabled, the V-source is placed in standby.

The V-source is configured from the :SOURce subsystem.

Note that the V-source for Auto-V-source Ohms is controlled from the :SENSe Subsystem.

Also see

None

:OUTPut2 subsystem

:LSENse <name>

This command is used to set the polarity of lines #1 through #4.

Usage

:OUTPut2:TTL[1]:LSENse <name>

:OUTPut2:TTL2:LSENse <name>

:OUTPut2:TTL3:LSENse <name>

:OUTPut2:TTL4:LSENse <name>

:LSENse?

<name>

 AHIGh: Sets polarity of specified line to active high

 ALOW: Sets polarity of specified line to active low

Details

This command is used to set the polarity of the digital output lines. When set for active high (AHIGh)

polarity, the specified output line is true (ON) when the output level is high. The output line is false

(OFF) when the output level is low. When set for active low (ALOW) polarity, the output line is true (ON)

when the output level is low. The output line is false (OFF) when the output level is high.

The logic levels (true or false) of the digital output lines are set from the SOURce Subsystem.

Also see

None
