Section 9: Filters and math Model 6517B Electrometer Reference Manual

9-6 6517B-901-01 Rev. C / August 2015

Configuring the filters

Each measurement function has its own filter configuration and is summarized in the following table.

Filter configuration menu

Menu item Description

FILTER

AVERAGING

TYPE

NONE

AVERAGING

ADVANCED

AVERAGING-MODE

MEDIAN

DISABLE

ENABLE

Filter menu:

Configure digital averaging filter:

Select type of average filter:

No average filtering performed

Program a simple average filter (1-100 rdgs.)

Program a simple average filter (1-100 rdgs.) with noise

tolerance (0-100 % of range)

Select moving average or repeating average mode

Configure median filter:

Disable median filter

Enable median filter and specify range (1-5)

Choosing the filter parameters for each function follows the same procedure. There are three ways to

display a filter configuration menu:

 To configure the filter of the present function, press CONFIG, then FILTER.

 To configure the filter of another function and remain in the present function, press CONFIG, then

the appropriate function key, then select FILTER from its menu.

 To configure the filter of another function and change to that function, press CONFIG, then the

appropriate function key, then FILTER.
