Keithley 6517B Reference Manual

Section 7: Triggering Model 6517B Electrometer Reference Manual
7-10 6517B-901-01 Rev. C / August 2015
Configuring measure layer
The measure layer is used for the following operations:
 To select the measuring event (SOURCE) for the instrument
 To delay operation in the measure layer
 To designate the number of measurements the instrument makes (COUNT)
 To enable or disable the source Bypass
The measure layer is configured from the MEASURE item of the ADVANCED TRIGGERING menu.

Keithley 6517B Specifications

General

Input Impedance	>200 TΩ
Electrometer Type	Electrometer/High Resistance Meter
Current Measurement Range	20 fA to 20 mA
Display	Vacuum Fluorescent Display
Communication Interfaces	IEEE-488 (GPIB), RS-232
Power Supply	100 V / 120 V / 220 V / 240 V; 50 Hz / 60 Hz
Resistance Measurement Range	Up to 200 TΩ
