In Arm Layer 1 and Arm Layer 2, enabling a source bypass also enables the respective output trigger.
In the trigger layer, its output trigger is always enabled and occurs after every device action. See
Output triggers (on page 11-20) for more information.
:IMMediate: Each time an :IMMediate command is sent, operation loops around the respective
control source. It is used when you do not wish to wait for the programmed event to occur (or
when the HOLD control source is selected). Note that in Arm Layer 1 and the trigger layer,
:IMMediate also loops operation around the delays.
:SIGNal: Same function as an :IMMediate command.
Delays
The scan layer and the measure layer have a programmable delay (0 to 999999.999 seconds) that is
enforced after an event detection.
