The common delay offset assures that the user-programmed turn-on delays will be synchronized to
start at the completion of the common delay offset. Query the delay offset of each unit and use the
slowest delay as the common delay offset.
Front Panel Menu Reference SCPI Command
Select Output\Sequence\Couple.
The Max delay offsetfor this frame field displays the delay
offsetof the unit. Enter the delay offset value of the slowest unit
in the Delay offsetfield in milliseconds. Then press Select.
To query the delay offsetof the slowest
unit:
OUTP:COUP:MAX:DOFF?
Use the delay offsetof the slowest unit to
specify the common delay offset
OUTP:COUP:DOFF .051
Keysight N6900/N7900 Series Operating and Service Guide 131
4 Using the Advanced Power System
