[SOURce:]CURRent:SLEW[:IMMediate] <value>|MIN|MAX|INFinity
[SOURce:]CURRent:SLEW[:IMMediate]? [MIN|MAX]
Sets the current slew rate. The slew rate is set in amps per second and affects all programmed
current changes, including those due to the output state turning on or off. The slew rate can be set to
any value between 0 and 9.9E+37. For very large values, the slew rate will be limited by the analog
performance of the output circuit. The keywords MAX or INFinity set the slew rate to maximum.
Parameter Typical Return
0 – 9.9E+37, *RST MAX <max value>
Sets the output slew rate to 1 A per second: CURR:SLEW 1
l The query returns the value that was sent, unless the value is less than the minimum slew rate, in
which case the minimum value is returned. The resolution of the slew setting is also the minimum
value, which can be queried using CURRent:SLEW? MIN. The exact value varies slightly according
to calibration.
[SOURce:]CURRent:SLEW:MAXimum 0|OFF|1|ON
[SOURce:]CURRent:SLEW:MAXimum?
Enables or disables the maximum slew rate override. When enabled, the slew rate is set to its
maximum value. When disabled, the slew rate is set to the immediate value set by the
[SOURce:]CURRent:SLEW command. Use [SOURce:]CURRent:SLEW? MAX to query the maximum
slew rate that was set.
Parameter Typical Return
0|OFF|1|ON, *RST ON 0or1
Enable the maximum slewrate: CURR:SLEW:MAX ON
l The [SOURce:]CURRent:SLEW:MAX command is coupled to the [SOURce:]CURRent:SLEW com-
mand. If [SOURce:]CURRent:SLEW sets the rate to MAX or INFinity,
[SOURce:]CURRent:SLEW:MAX is enabled. If the slew rate is set to any other value,
[SOURce:]CURRent:SLEW:MAX is disabled.
6 SCPI Programming Reference
221 Keysight N6900/N7900 Series Operating and Service Guide
