10.10 Option "FAN", ventilator control
To reduce the average noise emission of servo amplifiers with fan, these amplifiers can
be ordered with built-in fan option card (ventilator control). This option uses (invisible from
the outside) the expansion slot.
The option FAN cannot be inserted later. Order the amplifier with built-in FAN option.
Function
The fan is switched on and off depending on measured temperature values and brake
power. That reduces the average noise emission.
Switching temperature
Monitoring Fan off Fan on
Internal temperature < 55°C > 58°C
Heat sink temperature < 60°C > 65°C
Brake resistor (internal) < 20W > 30W
132 S300 Instructions Manual
Expansions Cards 02/2017 Kollmorgen
