8.12.4 Sine Encoder with BiSS analog (X1)
Wiring of a single-turn or multi-turn sine-cosine encoder with BISS interface as a feed
-
back system (primary and secondary, ð p.66). The thermal control in the motor is con
-
nected via the encoder cable to X1 and evaluated there.
If cable lengths of more than 50m are planned, please consult our customer service.
Frequency limit (sin, cos): 350 kHz
Type FBTYPE EXTPOS GEARMODE Up
5V analog (BiSS B) 23 - - 5V +/-5%
12V analog (BiSS B) 24 - - 7,5...11V
The pin assignment shown on the encoder side relates to the Kollmorgen motors.
70 S300 Instructions Manual
Electrical installation 02/2017 Kollmorgen
max. 250mA
0V
2
10k
10k
Sense
UP
UP
0V
B
A
-
+
A
B
12
10
8
4
15
3
11
5
13
10k
10k
-
+
9
1
X1
2
0V
11
12
10
13
15
4
8
5
3
CLOCK
CLOCK
Sense
UP
UP
0V
A+
A-
9
1
B-
B+
min. 5VDC/5mA
77
1414
voltage supply
Motor
sine
cosine
thermal control
Encoder
S300
SubD 15
round, 17-pin
