5 Package
5.1 Package supplied
When an amplifier from the S300 series is ordered (order numbers ðp.135), the following
is supplied:
— S3xx
— Mating connectors X0, X3, X4, X8
— Mating connector X9 only with SERVOSTAR 303-310 (S3xx6)
— Safety Guide S300 (printed)
— Electronic documentation on CD-ROM (PDF)
— Setup software DRIVEGUI.EXE on CD-ROM
The mating SubD connectors are not part of the package!
Accessories :
(must be ordered separately, if required; description see accessories
manual)
— Hybrid motor cable (prefabricated) for single cable connection
— motor cable (prefabricated) with special shield clamp, or both power connectors
separately, with the motor cable as a cut-off length
— feedback cable (prefabricated)
or both feedback connectors separately, with the feedback cable as a cut-off length
— motor choke 3YL, for motor cables longer than 25 meters
— external brake resistor BAR(U)
— communication cable to the PC (ð p.95) for setting parameters from a PC
— power cable, control cables, fieldbus cables (as cut-off lengths)
5.2 Nameplate
The nameplate is attached to the side of the servo amplifier.
The information described below is printed in the individual fields.
Picture similar to the original nameplate.
S300 Instructions Manual 21
Kollmorgen 02/2017 Package
Typenbezeichnung
Spannungsversorgung
Model Number
Power Supply
Ser. Nr
Nennstrom
Ser. No.
Nom. Current
Bemerkung
Schutzart
Comment
Encl.Rating
Umgebungstemp.
Surrounding temp.
1VD4
LISTED
IND. CONT. EQ.
CUS
U
L
®
5.18_ND0
123456789
Hardware
Revision
Made in
Austria
E217428
Kollmorgen Europe
Pempelfurtstraße 1
D-40880 Ratingen
GmbH
www.kollmorgen.com
Customer Support
Europe Tel. +49 (0)
Italy 3 36 594260
North America 1
2102 / 93940
Tel . + 9 0 2 /
Tel. + 540 633 3545
SERVOSTAR™ 310
123456789
S31061-NA
1x110-230V,3x115-230V 50/60Hz 4kVA
10A
40°C
04.10
IP20
RoHS
conform
CommentsSerial number
Servo amplifier type
max.
surrounding air
temperature
Output current
in S1 operation
Hardware
Revision
Enclosure Rating
Electrical supply
Installed load
