6.2.2 Technical data for 400/480 V (types S3_ _0_)
SERVOSTAR
Electrical data DIM 341 343 346
Order Code — S30101 S30301 S30601
Rated supply voltage (L1,L2,L3)
(grounded supply, phase to phase)
V~
3 x 208V
-10%
… 480V
+10%
, 50/60
Hz
Rated input power for continuous operation kVA 1.2 2.5 5
Permitted switch on/off frequency 1/h 30
Max. DC bus link voltage V= 900
Rated output current (rms value, ± 3%)
at 3x208V Arms 2 5 6
at 3x230V Arms 2 5 6
at 3x400V Arms 1.5 4 6
at 3x480V Arms 1.5 3 6
Peak output current (max. approx. 5s, ± 3%)
at 3x208V Arms 4.5 7.5 12
at 3x230V Arms 4.5 7.5 12
at 3x400V Arms 4.5 7.5 12
at 3x480V Arms 4.5 7.5 12
Switching frequency of the output stage kHz 8
at reduced current (50%) kHz 16
Voltage rise speed dU/dt (see hints on page 64!)
at 3x208V kV/µs 3,0
at 3x230V kV/µs 3,3
at 3x400V kV/µs 5,7
at 3x480V kV/µs 6,9
Technical data for brake circuit — ð p.30
Threshold for overvoltage switch-off
a 230V VDC 455
a 400V VDC 800
a 480V VDC 900
Motor inductance min.
at 3x208V mH 7.7 4.6 2.9
at 3x230V mH 8.5 5.1 3.2
at 3x400V mH 14.8 8.9 5.6
at 3x480V mH 17.8 10.7 6.7
Motor inductance max. mH Consult our customer support
Form factor of the output current
(rated conditions, min. load inductance)
— 1.01
Bandwidth of subordinate current controller kHz > 1.2
Residual voltage drop at rated current V 5
Thermal dissipation, output stage disabled W 12
Thermal dissipation at rated current
(incl. PSU losses, without brake dissipation)
W40 60 90
Noise emission max. dB(A) 25 45
Mechanical data
Weight kg approx. 2.7
Height, without connectors mm 270 279
Width mm 70
Depth, without connectors mm 171
Depth, with connectors mm < 230
26 S300 Instructions Manual
Technical description 02/2017 Kollmorgen
