Kollmorgen SERVOSTAR 300

8.8.2 24V auxiliary supply (X4)
— External 24V DC power supply, electrically isolated, e.g. via an isolating transformer
— Required current rating ð p.25
— Integrated EMC filter for the 24V auxiliary supply
8.8.3 Mains supply connection (X0), three phase
— Directly to 3-phase supply network, filter is integrated
— Fusing (e.g. fusible cut-outs) to be provided by the user ð p.27
8.8.4 Mains supply connection (X0), two phase without neutral
S300 Instructions Manual 59
Kollmorgen 02/2017 Electrical installation
DGND
DGND
+24V
+24V
+24V
39V
3
4
X4
2
1
PE
L3
L2
L1
S300
110...230V
50/60Hz
50/60Hz
208...480V
110...230V
50/60Hz
1
PE
PE
2
L3
F
N1
L3
L1
L2
3
4
L1
L2
F
N2
FN3
X0
S300
4
3
L2
L1
X0
2
1
L3
PE
50/60Hz
110...230V
FN2
FN3
L1
L2
PE
110...230V
50/60Hz
S300
