Auxiliary supply voltage 24V DC
l
Electrically isolated, internal fusing, from an external 24V DC power supply unit with,
for instance, isolating transformer or uninterruptible power supply.
Operation and parameter setting
l
With our user-friendly setup software, for setup via the serial interface of a PC.
l
If no PC is available: direct operation by two keys on the servo amplifier and a
3-character LED display.
l
Fully programmable via RS232 interface.
Completely digital control
l
Digital current controller (space vector, pulse-width modulation, 62.5 µs)
l
Adjustable digital speed controller (62.5 µs)
l
Integrated position controller, with adaptation possibilities for all applications (250 µs)
l
Integrated step/direction interface for connecting a servomotor to a stepper controller
l
Evaluation of resolver signals and sine-cosine signals of high-resolution encoders
l
Encoder emulation (incremental, compatible with A quad B or SSI)
Comfort functions
l
2 programmable analog inputs
l
4 programmable digital inputs
l
2 programmable digital outputs
l
programmable logical combinations of digital signals
Device Options
l
Option EtherCAT, cannot be inserted later, ð p. 131
l
Option FAN, ventilator control, cannot be inserted later, ð p.132
Expansions
l
I/O-14/08 expansion card, ð p.116
l
PROFIBUS DP expansion card, ð p.119
l
sercos
®
II expansion card, ð p.120
l
DeviceNet expansion card, ð p.122
l
SynqNet expansion card, ð p. 125
l
FB-2to1 expansion card, ð p. 127
l
-2CAN- expansion module, separated connectors for CAN-bus and RS232, ð p.129
l
Several third-party expansion cards (ModBus, LightBus, FIP-IO etc. please contact
the manufacturer for further information)
24 S300 Instructions Manual
Technical description 02/2017 Kollmorgen
