Kollmorgen SERVOSTAR 300 User Manual

Technical Data:
Brake circuit Supply voltage / V
Type Rated data DIM 115 230 400 480
303
(S30361)
Switch-on (upper) threshold of brake circuit V 200 400
—
Overvoltage F02 V 235 455
Internal brake resistor (RBint) Ohm 66 66
Continuous power for internal resistor (RBint) W 20 20
Max. brake power (average for 1s) kW 0,4 0,35
Pulse brake power kW 0,84 3
External brake resistor (RBext), optional Ohm 66 66
Continuous power for external resistor (RBext) kW 0,3 0,3
306 / 310
(S30661/S31061)
Switch-on (upper) threshold of brake circuit V 200 400
—
Overvoltage F02 V 235 455
Internal brake resistor (RBint) Ohm 66 66
Continuous power for internal resistor (RBint) W 50 50
Max. brake power (average for 1s) kW 0,84 0,88
Pulse brake power kW 0,84 3
External brake resistor (RBext), optional Ohm 66 66
Continuous power for external resistor (RBext) kW 1 1
341
(S30101)
Switch-on (upper) threshold of brake circuit V
—
400 720 840
Overvoltage F02 V 455 800 900
Internal brake resistor (RBint) Ohm 91 91 91
Continuous power for internal resistor (RBint) W 20 20 20
Max. brake power (average for 1s) 0,35 0,33 0,34
Pulse brake power kW 2,1 7 9
External brake resistor (RBext), optional Ohm 91 91 91
Continuous power for external resistor (RBext) kW 0,3 0,3 0,3
343 / 346
(S30301/S30601)
Switch-on (upper) threshold of brake circuit V
—
400 720 840
Overvoltage F02 V 455 800 900
Internal brake resistor (RBint) Ohm 91 91 91
Continuous power for internal resistor (RBint) W 50 50 50
Max. brake power (average for 1s) 0,91 0,86 0,85
Pulse brake power kW 2,1 7 9
External brake resistor (RBext), optional Ohm 91 91 91
Continuous power for external resistor (RBext) kW 1,0 1,0 1,0
Suitable external brake resistors can be found in our accessories manual.
S300 Instructions Manual 31
Kollmorgen 02/2017 Technical description
