Ch.4 Description of Screens
< 140 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
[Guard] Button
Used to guard the image of selected patient data and
protect it from deletion from the hard disk.
• Images from patient data that are guarded are indicated by
display of "G" in the "guard" item on the examination his-
tory screen.
• Touching the guarded patient data again removes the
guard.
[Edit] Button
Appears when the order that has been output is select-
ed.
• The image reference screen is displayed.
[Back] Button
Terminates the examination history screen and returns
to the system menu screen.
p.142 Image
Reference
Screen
p.128 System
Menu
Screen
Scroll Buttons [ ]
Scrolls the patient data list one item at a time.
Scroll Buttons [ ]
Scrolls the patient data list nine items at a time.
