Ch.3 Sequence of Examination
< 31 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
Once CS-3 is activated, the name of the examining operator must be selected.
Selection of Operator
1 Touch the
[KONICAMINOLTA]
button at the bottom left of
the initial screen.
(examination search screen
or examination list screen)
• The system menu will be
displayed.
2 Touch the [Operator] button.
• The operator selection screen will be displayed.
[KONICAMINOLTA]
Button
Initial Screen
3 Touch the button corresponding to your own
name on the list of operators' names followed by
the [OK] button.
• The display will return to the system menu.
4 Touch the [Back] button.
• The display will return to the examination search
screen.
• The selected operator name will be displayed at
the top left of the examination search and exami-
nation list screens.
When the system con-
figuration is set so that
operator data is sent
from a higher device,
operator selection from
CS-3 is not possible.
New registration of
operator name and
amendments of opera-
tor name may be effect-
ed using the user tool.
On systems where examination data is input from CS-3 only, the examination search screen is usually set as the initial
screen.
Prior to examination, patient data for the patient to be examined is input using the input panel (or the CS-3 keyboard)
on the CS-3 Operation Unit.
Patient Data Input (Input from CS-3)
1 Touch the patient ID input column.
• The input column will turn white and a character
input cursor will appear.
2 Touch the input panel and input the patient ID.
3 Touch the [ENTER] button.
• The next input window will turn white and a char-
acter input cursor will appear.
2
3
3
4
1
3
2
To Next Page
