Ch.4 Description of Screens
< 136 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
[Primary PRINTER1] Button
Sets the device as the primary printer.
[Secondary PRINTER2] [Secondary PRINTER3]
Button
Changes the output destination from the primary printer
to the backup (secondary) printer.
[Output] Button
Turns output to the printer ON/OFF.
[OK] Button
Terminates the printer status check screen.
Scroll Button [ ]
Scrolls the output queue display.
If the [OK] button is
touched on the exami-
nation check screen
with the [Output] button
kept OFF, only the out-
put queue will be stored
without being output.
Enables checking of the ID-680 Series status.
RIS Status Check Screen
There are two types of
ID-680 (for input and
output) that is connect-
ed to the system as
RIS.
RIS-IN1 on the left side.
System Status
Screen
RIS Status
Check Screen
(Input)
To Next Page
