Konica Minolta CS-3 User Manual

Ch.4 Description of Screens
< 123 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
Allocates and edits the annotation.
Annotation Setup Screen
Detailed Data
Setting Screen
(Overlay)
Annotation Setup
Screen
Image Display Field
Allocates the annotation.
Annotation can be allocated only on the
imaging area including the area out of colli-
mation. As in the example, a vertically long
object shown on the left, annotation cannot
be allocated in the areas at the both side
where no image is scanned.
p.66 Allocating
the
Annotation
Preset Button
Register the text strings that should be allocated as an
annotation. The text strings registered on each preset
button will not be aborted even after completion of the
examination or by power OFF.
p.68 Registering
the text
string on the
preset
buttons
