Ch.3 Sequence of Examination
< 46 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
The procedure for batch mode image output with the examination check screen in single-image format is
described below.
Image Output [Single-Image Format/Batch Mode Output of all Orders]
In cases where the automatic confirmation function is activated, after a specific time has elapsed from reading the
image, the confirmation process will be judged to be completed and the image will be output.
1 Check the image processing and overlay for all the
images exposed.
2 Touch the [Complete] button.
•A message will be displayed indicating that there
are images that are not specified to OK or NG.
3 Touch the [YES] button.
• All images will be output and examination termi-
nated.
• Display will return to either the examination search
or examination list screen.
• Touching the [NO] button will result to the exami-
nation check screen.
When outputting the image again even after the examination is completed, or out-
putting the image more than once, the second or later image will be output through
the "Image Reference Screen".
After batch mode out-
put of all orders, exami-
nation will be terminat-
ed and display will
return to the initial
screen (examination
search or examination
list screen).
p.81 Examination
Check
Screen
[Single-Image
Screen]
p.61
Image Reference
after Examination
(Output Again)
Depending on the set up at the time of installation,
either of the icons shown in the right may be printed on the
edge of output film(image data when output to the Host),
indicating the image is mirrored or not.
: not mirrored
: mirrored
2
3
To Next Page
