Konica Minolta CS-3 User Manual

Specification
< 196 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
These specifications
are subject to change
without notice due to
continual improve-
ments.
Bar Code Reader (Multi bar code reader)
Product name
Interface
Light Source
Readable Code
Safety Standard
Max. Laser Output Power
Laser Wavelength
Max. Readable Length
Resolution
Power Source
Current Consumption
Resistance to Shock
Operating Temperature
Storage Temperature
Humidity
Dimensions
Weight
MS 7120 Orbit
RS232C
Visible Laser Diode
Code 128
IEC825-1
1.0mW
630nm ~ 680nm
130mm
0.13mm
5.2 VDC
220mA
Normal reading is secured even after it is dropped on the
concrete ground from 1.0m height.
0 ~ 40
:
– 40 ~ 60:
5 ~ 95%RH
80(W) x 105(D) x 150(H) mm
380g (without cable.)

Konica Minolta CS-3 Specifications

General

Brand	Konica Minolta
Model	CS-3
Category	Medical Equipment
Language	English
