Reference • Program mode
168
This setting functions in the same way as the Attack
Time parameter.
Page 12: Vibrato
This page contains settings which control pitch modu-
lation. This function simulates the vibrato effects that
can be produced on many acoustic instruments.
For double oscillator programs, the pitch of each oscil-
lator can be modulated independently.
Vib.1/Vib.2 (Vibrato 1/Vibrato 2)
When a double oscillator program is selected, this
specifies the oscillator whose Vibrato parameter will
be edited.
You can also use the VARIATION buttons [1] and [2] to
switch between oscillators 1 and 2.
Waveform
[TRI…RANDM]
Selects the waveform that will be used to modulate the
pitch of the oscillator. The following waveforms are
available.
I (Intensity)
[00…99]
This sets the depth of automatic pitch modulation.
With a setting of 99, the selected waveform will modu-
late the pitch over a range of 1–2 octaves.
With a setting of 0, modulation will not be applied.
F (Frequency)
[00…99]
This sets the speed of pitch modulation.
Higher values will produce faster modulation.
VDA EG Time parameter settings
Notes played softly Notes played strongly
Note-offNote-offNote-offNote-on Note-on Note-on
Vib.1/Vib.2
Delay
Key sync
Fade in
Waveform Intensity
Keyboard tracking
Frequency
TRI - triangle wave
SAWUP - sawtooth wave (upward)
SAWDN - sawtooth wave (downward)
SQUAR - square wave
RANDM - random
Lower values Higher values
