Reference • Arrangement Play mode
64
Page 9: Effect select
The instrument has two incorporated digital effect
processors for the sounds produced by the internal
sound generator. In this page, you can choose which
effects you wish to assign to an arrangement and turn
them on or off. For more details, see page 175.
Page 10: Effect modulation
In this page you can connect the effects to controls,
which allow you to dynamically modulate their inten-
sity. For more details, see page 176.
Page 11: Effect placement
In this page you can choose the effect setup of the
arrangement, and program pan and levels for chan-
nels C and D. Pan and sending of arrangement tracks
are programmed on “Page 3: Track settings (1)”. For
more details, see page 177.
Page 12: Effect 1 settings
Page 13: Effect 2 settings
These pages contain the effect parameters selected on
“Page 9: Effect select”, that will be used for the
selected arrangement. The parameters contained in
these pages will depend on the effects you have
selected. For more information on programming
effects, see page 178.
