Korg i40M User Manual

Reference • Appendices
202
MIDI Implementation chart
Function Transmitted Recognized Remarks
Basic Channel
Default 1–16 1–16 Memorized
Changed 1–16 1–16
Mode
Default 3
Messages X X
Altered ******************
Note
Number:
0–127 0–127
Transmit from sequencer
True Voice ****************** 0–127
Velocity
Note On O 9n, V=1–127 O 9n, V=1–127
Transmit 2-126 from sequencer
Note Off X X
Aftertouch
Polyphonic (Key) O O Sequencer data only *A
Monophonic (Channel) O O Sequencer data only *A
Pitch Bend O O Sequencer data only *C
Control
Change
0, 32 O O
Bank Select (MSB, LSB) *P
1, 2 X O
Modulation (pitch, cutoff) *C
4, 64 O O
Pedal (scale, damper) *C
6, 38 X O
Data Entry (MSB, LSB) *E
11 X O
Expression *C
7, 10, 91, 93 O O
Volume, A:B panpot, send C, D *C
12 O O
Effect controller *C
72, 73, 74 X O
EG time (Release, Attack), Brightness *C
92 ,94 O O
Effects 1, 2 on/off *C
96, 97 X O
Data Inc, Dec *E
100, 101 X O
RPN (LSB, MSB) *2
120, 121 X O
All sound off, Reset all Cntrls
0–101 O O
(Sequencer data)
Program
Change
O 0–127 O 0–127 *P
True # ****************** 0–127
System Exclusive O O *3 *E
System
Common
Song Position O O *1
Song Select O 0 O 0 *1
Tune X X
System
Real Time
Clock O O *1
Commands O O *1
Aux
Messages
Local On/Off O X In case Echo back is active.
All Notes Off X O (123–127)
Active Sense O O
Reset X X
Notes
*C, *P, *A, *E: Sent and received when MIDI Filter (Controller, Program Change, Aftertouch, System Exclusive) is set
to ENA in Global mode.
*1: When clock is set to internal, sent but not received. When set to external, received but not sent.
*2: LSB, MSB = 00,00: pitch bend range, =01,00: fine tune, =02,00: course tune
*3: Includes Inquiry, GM Mode On, Master Balance, and Master Volume messages.
Mode 1:OMNI ON, POLY
Mode 3:OMNI OFF, POLY
Mode 2:OMNI ON, MONO
Mode 4:OMNI OFF, MONO
O: Yes
X: No
KORG i40M
OS Version 1.0 - Feb. 20, 1999
