Reference • Appendices
221
Technical specifications
Features
Generation system AI
2
Synthesis System
Tone generator 32voices, 32 oscillators
Sample memory 14MB PCM ROM
Effects Two stereo digital multi-effect systems, 47 effects, edit function
Vocal/Guitar section
Input sensitivity: Microphone, Guitar, Line (Mono).
Controls: Volume, A/B programmable knob, C programmable button (mute).
LED indicator: Signal (presence and clip).
Vocal model: 4 harmonization voices, separate MIDI channel for the Arrangement Play, Back-
ing Sequence and Song Play modes.
Vocal mode effects: Compressor, Tone controls, Chorus/Delay, 2 Reverbs.
Guitar mode effects: 3 Drive, Tone controls, Noise reduction, Speaker simulator, 7 Modulating
effects, 3 Ambience effects.
Programs
320 programs (including GM programs) + 14 drum kits + 64 USER programs + 2 USER drum
kits
Styles 128 styles + 16 USER styles
Arrangements 128 arrangements + 64 USER arrangements
Keyboard Set 15
Song Reads SMF in format 0 and 1 (16 tracks), GM compatible, Lyrics function
Backing Sequence 10, stored in RAM (40,000 events)
External controls Damper Pedal, Assignable Pedal/Switch, EC5
Audio outputs Left/Mono, Right
Audio inputs Mic/Gtr with gain control
MIDI In 1, In 2, Out, Thru
Floppy Disk 3,5” 2DD/2HD (MS-DOS® 1,44 MB and 720KB, IBM-PC® and Macintosh® compatible)
Display Backlit custom LCD
Dimensions (W x D x H) 400 x 287 x 87 mm (15.7 x 11.2 x 3.4 inch)
Weight 4,3kg (9.5 lbs)
