Installation
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 49
Fig.: 21 Placing flat seals on rear of adapter plate
IMPORTANT INFORMATION
The drive controller may not be installed without an adapter plate!
5. Find a position that meets the required ambient conditions (see 3.3 "Installation requirements"
section).
6. Carefully place flat seals (6) on the rear of adapter plate (1).
