2 Introduction
For electrical schematics, refer to the schematics provided with your EXPERT™ unit;
For pneumatic and hydraulic schematics, refer to the schematics provided with your E
XPERT™ unit.
NOTE: A number of system schematics are included in this manual.
Warranty Registration Form
Do not forget to complete the owner registration form and to send it to Labrie Enviroquip Group.
Make sure to fill out the in-service date. This date will be used as the start date of the warranty period.
If the in-service date is not indicated, the warranty period will start 30 days after the delivery date.
Introducing the EXPERT
The EXPERT™ is a versatile side-loading vehicle manufactured to the highest standards and designed
to collect residential and commercial refuse as well as recycling materials. Because of its drop-frame
configuration (see Figure 1-1), the E
XPERT™ is perfect for manual or semi-automated waste/
recyclables collection. A loading height of only 5.5 inches above the chassis frame makes this
configuration safer, faster and easier to load. The hopper can be accessed from both curbside and
streetside, making collection in alleys and one-way streets quick and productive.
Figure 1-1
Drop-frame chassis
The EXPERT™ may be equipped with an automated Zero-Grab lifting arm, called “HELPING-HAND™”
arm, for efficient automated waste/recyclables collection. The H
ELPING-HAND™ arm can reach roller
carts that are up to 10 feet from the truck and can lift carts of up to 400 lbs when fully extended. The
H
ELPING-HAND™ arm is easy to operate with an electric over hydraulic joystick control, and the Zero-
Grab low swing-out makes it easy to collect refuse in narrow spaces. Also, on some units, the E
XPERT
is equipped with 2 automated lifting arms, one on each side of the truck, perfect for waste/recyclables
collection in alleys and one-way streets.
The E
XPERT™ can be further customized to meet your needs. Many options are offered including:
glass compartment, organic bucket tipper, modified cab and many different split body configurations,
with optional single or split hydraulic chute. An optional cart tipper can be added and installed on
either side of the truck or on both sides for adequate semi-automated waste/recyclables collection.
