Labrie EXPERT Service Manual

Electrical System 315
NOTE: Consult the OEM manual for information on equipment not manufactured by Labrie
Enviroquip Group.
The following table provides a description of the circuit breakers located in the control box inside the
truck cab.
Limit and Proximity Switches
Limit and proximity switches act as remote electrical ON/OFF switches.
The following is a list of limit and proximity switches that are installed on an E
XPERT™ unit. Some of
them are optional.
 Packer fully retracted proximity switch
 Packer fully extended proximity switch
 Hopper door fully open limit switch (optional)
 Tailgate unlocked proximity switch
 Tailgate fully open proximity switch (optional)
 Arm stowed limit switch(es) (optional)
 Arm extended & arm parked limit switches (optional)
 Crusher panel up limit switch (optional)
 Body-raised limit switch
 Chute limit switch (optional)
For details on limit and proximity switch adjustment, go to page 200 and the following.
Function Ampere Circuit Number
Monitor (W2) 7.5 141
Cab fan (W3) 15 135
Scale Air-Weigh System power & acc. (W4) 10 161
Electronic controller (W5) 10 168
Warning!
Limit and proximity switches must operate properly. Improperly adjusted limit/proximity
switches may cause serious damage or even death.
