7
Pneumatic System
The air (pneumatic) system is crucial for efficient
brake and body operation.
NOTE: Before searching for parts, identify the type of cab
of your unit (cab over or conventional). The
mounting of some components for the body
depends on the type of cab configuration.
On most E
XPERT™trucks, the main hydraulic valve,
which controls body functions, is activated by air
actuators.
Figure 7-1
Air actuators
Air actuators
