General Maintenance 179
4. Use shims as required for proper adjustment.
Figure 3-257
Packer wiper blades
Follower Panels
Replacing Roller Assemblies
Packer rollers need to be replaced when damaged or when showing excessive wear or flat spots. The
procedure outlined below will show you how to remove both bottom and top rollers and how to
replace them.
A. Standard Units W/ Loading Arm and Dual HELPING-HANDUnits
NOTE: For standard and co-mingle units with no loading arm, go to page 183; for co-mingle units with
loading arm, go to page 184.
To replace the panel roller assemblies:
1. Start the engine and engage the hydraulic pump.
2. Fully extend the packer, then push the red emergency STOP button to maintain the packer in its
fully extended position.
3. Turn OFF the hydraulic pump and the engine.
4. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 14).
5. Open the left/right hand side hopper door.
6. Remove the anti-spill guards located on each side of the hopper (see Figure 3-258).
An R-pin located just behind the anti-spill guard (see Figure 3-259) must be pulled completely to
allow for the removal of the guard.
Danger!
Do not enter the hopper while the packer is moving.
