156 General Maintenance
Figure 3-218
5/8” nut
8. Remove the divider guard.
4 bolts are to be taken out to remove the divider guard (2 on each end).
Figure 3-219
Divider guard
9. Remove the chute (see Figure 3-220). To perform this task, apply the following steps:
9 a. Use a suitable lifting device (e.g. sling or cable) to hold the chute in place.
9 b. Start the truck and engage the hydraulic pump.
9 c. Lower the crusher panel(s), if installed, using the CRUSHER PANEL DOWN switch on the in-
cab control panel.
Danger!
Never enter the hopper while the hydraulic system is engaged.
