192 General Maintenance
6. Using a 9/16-inch box and a wrench, remove all 6 bolts that hold the follower panels to the
packer (see Figure 3-282).
NOTE: It is possible to remove the first bolts through the clean-out traps. To remove those that are
closer to the center, go between the cab and the hopper.
Figure 3-280
Bolt accessible through clean-out trap
Figure 3-281
Center bolts accessible between cab and hopper
