General Maintenance 195
If the gap between the gland and the tube is wider than 1⁄8 inch, you must call LabriePlus
immediately. Should the gap between the tube and the gland be wider than 1 inch, you must stop
using the vehicle immediately and repair the cylinder (see Replacing Body Hoist Cylinder on
page 196).
Figure 3-285
Gap on cylinder section
6. Make sure that the gland safety pins are in place.
Figure 3-286
Safety pin
7. When the inspection is completed, put back the safety prop and lower the body.
Danger!
It is mandatory to inspect all cylinder glands weekly. If one of the cylinder glands is
unscrewed from the body hoist cylinder, it will cause separation of the hydraulic cylinder,
and the body will drop suddenly.
This type of accident can lead to damage, serious injury, and even death.
Less than
1/8˝ gap
