FAULT
CODE
SPN FMI DESCRIPTION
351 3597 12 Injector power supply. Bad intelligent device or component.
415 100 1
Engine oil rie pressure. Data valid but below normal operational range. Most severe
level.
418 97 15 Water in fuel indicator. Data valid but above normal operating range. Least severe level.
428 97 3 Water in fuel indicator sensor circuit. Voltage above normal or shorted to high source.
429 97 4 Water in fuel indicator sensor circuit. Voltage above normal or shorted to low source.
431 558 2 Accelerator pedal or lever idle validation switch. Data erratic, intermittent or incorrect.
432 558 13 Accelerator pedal or lever idle validation switch circuit out of calibration.
435 100 2 Engine oil rie pressure. Data erratic, intermittent or incorrect.
441 168 18 Battery 1 voltage data valid but below normal operating range. Moderately severe level.
442 168 16 Battery 1 voltage data valid but below normal operating range. Moderately severe level.
449 157 0
Injector metering rail 1 pressure. Data valid but above normal operational range. Most
severe level.
451 157 3
Injector metering rail 1 pressure sensor circuit voltage above normal or shorted to high
source.
452 157 4
Injector metering rail 1 pressure sensor circuit voltage below normal or shorted to low
source.
523 611 2 Auxiliary intermediate speed switch validation data erratic, intermittent or incorrect.
527 702 3 Auxiliary input/output 2 circuit voltage above normal or shorted to high source.
528 93 2 Auxiliary alternate torque validation switch data erratic, intermittent or incorrect.
529 703 3 Auxiliary input/output 3 circuit voltage above normal or shorted to high source.
553 157 16
Injector metering rail 1 pressure data valid but above normal operating range. Moderately
severe level.
559 157 18
Injector metering rail 1 pressure data valid but below normal operating range. Moderately
severe level.
584 677 3 Starter relay driver circuit voltage above normal or shorted to high source.
585 677 4 Starter relay driver circuit voltage below normal or shorted to low source.
599 640 14 Auxiliary commanded dual output shutdown.
649 1378 31 Engine oil change interval condition exists.
689 190 2 Engine crankshaft speed/position data erratic, intermittent or incorrect.
691 1172 3
Turbocharger 1 compressor intake temperature circuit voltage above normal or shorted to
high source.
692 1172 4
Turbocharger 1 compressor intake temperature circuit voltage above normal or shorted to
low source.
697 1136 3 Engine ECU temperature sensor circuit voltage above normal or shorted to high source.
698 1136 4 Engine ECU temperature sensor circuit voltage above normal or shorted to low source.
731 723 7
Engine speed/position camshaft and crankshaft misalignment. Mechanical system not
responding or out of adjustment.
778 723 2 Engine camshaft speed/position sensor data erratic, intermittent or incorrect.
1117 3597 2 Power supply lost with ignition on. Data erratic, intermittent or incorrect.
1239 2623 3
Accelerator pedal or lever position sensor 2 circuit voltage above normal or shorted to
high source.
5
Maintenance
LeeBoy 685D Motor Grader 5-53
