LUBRICATION
Proper lubrication is very important for maintaining the machine at top efciency. Use multi-purpose grease to
lubricate the grease points shown below. Additional lubrication requirements are described on the following pages.
Grease Points
2
1
1
3
4
5
6
7
7
9
10
11
12
13
14
8
16
17
15
15
Maintenance
LeeBoy 685D Motor Grader5-6
