LeeBoy 685D - Page 213

Boom Articulation
Item
No
Part Number Qty Description Remarks
REF 1018345 2 Articulation Cylinder Assembly w/Adapters Includes Items 1-4
1 1018413 2 Hydraulic Cylinder, 3.00 x 9.00 x 1.25
2 FS6400-06-06-O 4 Straight Adapter, -6 ORFS/-6 O-Ring
3 210060 4 Clevis Pin, 1.00 x 2.63 w.1.50 Head
4 80338 4 Cotter Pin, .188 x 2.00
5 220360 4 Bushing, 1.00 ID x 1.25 OD x 1.00
6 100071 2 Articulation Clamp Half
7 100-10-18-80-8 8 CSHH, 5/8-18 x 5.00, GR8
8 307-10 8 Washer, Lock, Hi-Collar, 5/8
9 310-10 8 Washer, Hardened, SAE, 5/8
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-5
