LeeBoy 685D - Page 219

Front Axle Assembly, 2WD (1 of 3)
Item
No
Part Number Qty Description Remarks
1 1018076 1 Front Axle Assembly - 2WD See Figure 7-5
2 988328 2 Front Axle Clamp
3 100-10-11-24-8F 4 CSHH, 5/8-11 x 1.50, GR8, FT
4 302-10 4 Washer, Lock, 5/8
5 1018086 1 Front Axle Pin
6 A120330AR 1 Tire/Wheel Assembly - Right
7 A120330AL 1 Tire/Wheel Assembly - Left
REF 110340 2 Tire, 15" x 19.5", 8 Ply Included with 6 & 7
REF 120330B 2 Wheel Included with 6 & 7
REF 20192233 2 Valve Stem Included with 6 & 7
8 1009420 16 Lug Nut
REF 1018364 2 Cover Plate Assembly w/Adapters Includes Items 9-17
9 1018223 2 Cover
10 FS0304-C-06 2 Adapter Cap, -6 ORFS
11 FS2700-06-06 2 Bulkhead Union Adapter, -6 ORFS/-6 ORFS
12 0306-06 2 Bulkhead Lock Nut, -6
13 1018392 2 Connector, 6 Pin,
14 122-#8-32-12F 4 PHMS, Cross, #8-32 x .75, FT
15 300-#8 4 Washer, Flat, SAE, #8
16 302-#8 4 Washer, Lock, #8
17 209-#8-32 4 Nut, Hex, Mach, #8-32
18 100-4-20-16-5 8 CSHH, 1/4-20 x 1.00, GR5
19 302-4 8 Washer, Lock, 1/4
20 300-4 8 Washer, Flat, SAE, 1/4
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-11
