LeeBoy 685D - Page 223

Item
No
Part Number Qty Description Remarks
1 110033SRV 1 Front Spindle Mount - Right
2 110043SRV 2 Front Spindle Mount - Left
3 110130 3 Tie Rod Bushing, 1.25 ID x 1.50 OD x 1.00 LG
4 852827 4 Clamp Half
5 100-10-11-48-5 8 CSHH, 5/8-11 x 3.00, GR5
6 302-10 8 Washer, Lock, 5/8
7 110151 2 Front Wheel Lean Pin
8 140610 2 Lube Fitting, Straight, 1/4-28
9 1018081 1 Steering Arm with Axle - Right Includes Item 10 (x2)
10 1018080 1 Steering Arm with Axle - Left Includes Item 10 (x2)
11 210190 4 Bearing Cup (x2) Not Shown
12 110101 2 Machined Nut
13 210240 2 Seal
14 210180 2 Bearing Cone
REF 110061 2 Front King Pin
15 110240A 2 Wheel Hub Assembly w/ Studs Includes Items 15-18
16 988911SRV 2 Wheel Hub
17 110250 2 Wheel Hub Inner Bearing Cup
18 610200 2 Wheel Hub Outer Bearing Cup
19 110350A 16 Wheel Stud
20 36830 2 Seal
21 110260 2 Wheel Hub Inner Bearing Cone
22 610210 2 Wheel Hub Outer Bearing Cone
23 110300 2 Front Spindle Thick Washer
24 110310 4 Front Spindle Nut
25 110320 2 Front Spindle Lock Washer
26 110330 2 Dust Cap
Front Axle Assembly, 2WD (3 of 3)
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-15
