LeeBoy 685D - Page 227

Item
No
Part Number Qty Description Remarks
REF 1018102 1 AWD Front Axle Assembly
1 1018103 1 AWD Front Axle Includes Items 2,3
2 984625 2 Front Yoke Groove Bushing
3 984625-1 2 Bushing
4 110161 1 Lean Cylinder Pin
5 400-6-28 1 Roll Pin, 3/8 x 1.75
6 140615 1 Lube Fitting, 45°, 1/4-28
7 857377 4 Spindle Mounting Clamp - AWD
8 100-10-11-40-5 8 CSHH, 5/8-11 x 2.50, GR5
9 302-10 8 Washer, Lock, 5/8
10 1019767 1 Hydraulic Cylinder, Steering, 2.50 x 12.50 x 1.50 Steering - AWD
11 FS6802-06-06-NWO-FG 1 Elbow Adapter, 45°, -6 ORFS/-6 ORFS
12 FS6801-06-06-NWO-FG 3 Elbow Adapter, 90°, -6 ORFS/-6 ORFS
13 214-20-12-5 4 Nut, Heavy Hex, 1-1/4-12, GR5
14 110210 3 Ball Joint - Right
15 110192 1 Steering Tie Rod
16 110200 1 Ball Joint - Left
17 1018674 1 Hydraulic Cylinder, 3.50 x 5.00 x 1.50 Front Wheel Lean
18 140610 2 Lube Fitting, Straight, 1/4-28
19 110141SRV 3 Front Wheel Lean Tie Pin
20 110170 2 Front Wheel Lean Clevis
21 855002 3 Washer, Flat, 1-1/4 ID x 2-1/16 OD
22 80338 3 Cotter Pin, 3/16 x 2.00
23 859375 1 Tie Rod, Wheel Lean
OPTION-Front Axle Assembly, AWD (2 of 3)
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-19
