OPTION-Front Axle Assembly, AWD (3 of 3)
Item
No
Part Number Qty Description Remarks
1 986366SRV 1 AWD Spindle Mount - Right Includes Items 3,4
2 986365SRV 1 AWD Spindle Mount - Left Includes Items 3,4
3 110130 3 Wheel Lean Tie Rod Bushing
4 210040 4 Inner Race Bearing
5 857368 2 AWD Wheel Lean Shaft
6 140610 2 Straight Lube Fitting, 1/4-28
7 1018091 1 AWD Steering Arm Assembly - Right Includes Item 9
8 986363SRV 1 AWD Steering Arm Assembly - Left Includes Item 9
9 101-10-11-32-5 8 CSHH, Heavy, 5/8-11 x 2.00, GR5
10 302-10 8 Washer, Lock, 5/8
11 1019685-01 2 Torque Hub & Casting
12 FS6400-08-12-O 4 Straight Adapter, -8 ORFS/-12 O-Ring
13 FS6400-08-08-O 2 Straight Adapter, -8 ORFS/-8 O-Ring
7
Illustrated Parts List
LeeBoy 685D Motor Grader 7-21
